Topaz

topaz 85s

With TOPAZ 85s, Adiatek brings a new sweeping machine in the market, taking all the autonomy and ergonomics standards of the scrubbing version.

This model is equipped with an 85cm brushes base and a side brush, thanks to which the dirt is collected also along walls and corners, moving it under the machine to be collected in the dedicated van.

The machine is provided with a 3S dosing system as standard equipment, the possibility to adjust the brushes base pressure on 8 levels depending on how much the brushes are worn and also the chance to choose between the standard and quiet mode for the suction motor.

TOPAZ 85s can be equipped with several optional equipment as the water and detergent dosing system (3SD system), the TELEMATICS and the side brooms supports.

Theoretical productivity: 6375 m²/h

Characteristics

Ride-on machine with traction

Power supply 36V/320Ah

Cleaning width 850mm

Brushes pressure adjustable - - -

Battery autonomy 3,5-4,5h

Solution tank / recovery tank 180/190l

Cylindrical brushes 2x150mm

Brushes speed 785rpm

Technical data

Squeegee width

1100 mm

Brushes motor

2x650 Watt

Motion system

automatic

Maximum gradient

10%

Suction motor

2x570 Watt

Suction vacuum

190 mbar

Machine length

1962 mm

Machine width

985 mm

Machine height with rollbar

1865 mm

Machine height without rollbar

1613 mm

Machine weight w/o battery

445 kg

Traction motor

1200 Watt

Maximum forward speed

7.5 km/h

Batteries compartment length

620 mm

Batteries compartment width

540 mm

Batteries compartment height

460 mm

Class

|||

Protection level

IP X3

oudness

<70 dB (A)

Brushes and pad holder

Brushes

Material: NYLON<br />Ø brush: 150 mm <br />Length: 800 mm<br />Ø bristle: 0,3 mm <br />Cod: 48906090

Material: NYLON
Ø brush: 150 mm
Length: 800 mm
Ø bristle: 0,3 mm
Cod: 48906090

Material: PPL<br />Ø brush: 150 mm <br />Length: 800 mm<br />Ø bristle: 0,7 mm <br />Cod: 48906010

Material: PPL
Ø brush: 150 mm
Length: 800 mm
Ø bristle: 0,7 mm
Cod: 48906010

Material: PPL<br />Ø brush: 150 mm <br />Length: 800 mm<br />Ø bristle: 1 mm <br />Cod: 48906050

Material: PPL
Ø brush: 150 mm
Length: 800 mm
Ø bristle: 1 mm
Cod: 48906050

Material: abrasive bristles<br />Ø brush: 150 mm <br />Length: 800 mm <br />Cod: 48906070

Material: abrasive bristles
Ø brush: 150 mm
Length: 800 mm
Cod: 48906070

Material: PPL long bristles<br />Ø brush: 500 mm <br />Ø bristle:0,6 mm <br />Cod: 48916100

Material: PPL long bristles
Ø brush: 500 mm
Ø bristle:0,6 mm
Cod: 48916100

Batteries and chargers

36V 320Ah5 tubular battery

36V/40A high frequency lead battery charger (500Ah5)

Accessories

Coupling assembly accessories

Softer rear wheel 70SH

Equipment Standard equipment:

Optional:
