Jade

jade 50

Single brush version with a cleaning width of 50 cm. The strong and silent aluminium brush base is provided with a geared motor designed by Adiatek.

This machine is suitable for all those situations where it is important the frequent cleaning of the brush as this model is provided with an automatic docking system for the bush that does not require the manual intervention.

The machine is perfect for hospital, schools and all the environments where the care for the hygiene is more important.

Theoretical productivity: 2250 m²/h

Characteristics

Walk behind machine with traction

Power supply 24V/180Ah

Cleaning width 508mm

Brushes pressure adjustable max.36kg

Battery autonomy 3-5h

Solution tank / recovery tank 53/56l

Disc brush 1x508mm

Brushes speed 165rpm

Technical data

Squeegee width

850 mm

Brushes motor

600 Watt

Motion system

automatic

Maximum gradient

10%

Suction motor

400 Watt

Suction vacuum

120 mbar

Machine length

1335 mm

Machine width

590 mm

Machine height

1078 mm

Machine weight w/o battery

101 kg

Traction motor

180 Watt

Minimum forward speed

3.2 km/h

Maximum forward speed

4.5 km/h

Batteries compartment length

405 mm

Batteries compartment width

390 mm

Batteries compartment height

374 mm

Class

|||

Protection level

IP X3

oudness

68.5 dB (A)

Brushes and pad holder

Brushes

Material: PPL<br />Ø brush: 508 mm<br />Ø bristle: 0,3 mm <br />Cod: 48902010

Material: PPL
Ø brush: 508 mm
Ø bristle: 0,3 mm
Cod: 48902010

Material: PPL<br />Ø brush: 508 mm<br />Ø bristle: 0,6 mm <br />Cod: 48902050

Material: PPL
Ø brush: 508 mm
Ø bristle: 0,6 mm
Cod: 48902050

Material: PPL<br />Ø brush: 508 mm<br />Ø bristle: 0,7 mm<br />Cod: 48902020

Material: PPL
Ø brush: 508 mm
Ø bristle: 0,7 mm
Cod: 48902020

Material: PPL<br />Ø brush: 508 mm<br />Ø bristle: 0,9 mm <br />Cod: 48902030

Material: PPL
Ø brush: 508 mm
Ø bristle: 0,9 mm
Cod: 48902030

Material: Mix 5<br />Ø brush: 508 mm <br />Cod: 48902060

Material: Mix 5
Ø brush: 508 mm
Cod: 48902060

Material: abrasive bristles<br />Ø brush: 508 mm<br />Ø bristle: 1,2 mm<br />Cod: 48902040

Material: abrasive bristles
Ø brush: 508 mm
Ø bristle: 1,2 mm
Cod: 48902040

Pad Holder

Pad holder cl green
Ø disc: 495 mm
Cod: 48802010

Batteries and chargers

12V 110Ah5 tubular battery

12V 105Ah5 gel battery

12V 120Ah5 flat plate battery

3x2V 180Ah5 tubular battery with plastic banded elements

Battery charger 24V/12A high frequency lead and gel

Standard lead 24V/15A battery charger (110Ah)

Standard lead 24V/20A battery charger (120Ah)

Standard 24V/30A (180Ah) lead battery charger

Battery charger 24V/20A CBHD3

Battery charger on board

Accessories

Hose water load

Cap with hose for the water loading

Elastic for traction

3 stages suction motor

Silenced suction motor

Stainless steel chain for the solution tank cap

External speed adjustment

EquipmentOptional:

3S system

Ozone system

Download

Product sheet
